VDE APPROVED CABLE
Verband der Elektrotechnik, Elektronik und Informationstechnik – more commonly known as VDE – is the Association for Electrical, Electronic and Information Technologies and their related sciences, technologies and applications.

The DKE German Commission for Electrical, Electronic & Information Technologies, a joint organization of the DIN (German Institute for Standardization) and the VDE, is the national organization responsible for creating and maintaining standards in these fields. Drawing on the expertise and work of about 5,500 voluntary professionals, the DKE represents Germany in the European and international bodies responsible for standardization.

Standards developed jointly between VDE and DIN, the German Institute for Standardisation (Deutsches Institut für Normung e.V.), are promoted under the banner of DKE, the German Commission for Electrical, Electronic and Information Technologies.

DIN VDE CABLE STANDARDS

Basic Safety Aspects and Power Installations
DIN VDE 0100 - Erection of power installations with rated voltages below 1000V
DIN VDE 0100 - Part 100 - General requirements
DIN VDE 0100 - Part 410 - Protective measures and protection against electric shock
DIN VDE 0100 - Part 430 - Protection of cables against overcurrent
DIN VDE 0100 - Part 482 - Choice of protective measures, protection against fire
DIN VDE 0100 - Part 520 - Selection and erection of equipment - cable, wires and wiring systems
DIN VDE 0100 - Part 530 - Erection of electrical equipment - switch and controlgear
DIN VDE 0100 - Part 559 - Luminaries and lighting equipment
DIN VDE 0100 - Part 701 to Part 705 - Rooms containing a bathtub or shower basin. Roofed swimming pools and open air swimming baths. Rooms containing electrical sauna-heaters. Agricultural and horticultural premises
DIN VDE 0100 - Part 720 - Fire hazard locations
DIN VDE 0100 - Part 726 to Part 738 - Lifting and hoisting devices. Laying of cables in hollow walls and in buildings made up mainly of flammable building materials. Cable entries into buildings in public cable network. Humid and wet areas, outdoor installation DIN VDE 0100 - Part 0101 - Erection of power installations with rated voltages above 1000V
DIN VDE 0105 - Operation of power installations
DIN VDE 0107 - Electrical installations in hospitals and locations for medical use outside hospitals
DIN VDE 0108 - Part 1 to Part 100 - Power installations and safety power supply in communal facilities, stores and shops and exhibition rooms, multi-storey buildings, restaurants, closed car parks and working or business premises
DIN VDE 0113 - Electrical equipment of industrial machines
DIN VDE 0118 - Erection of electrical installations in mines
DIN VDE 0165 - Installation of electrical apparatus in hazardous areas
DIN VDE 0166 - Electrical installations and apparatus thereof for use in atmospheres potentially endangered by explosive material
DIN VDE 0168 - Erection of electrical installations in open cast mines, quarries and similar plants
DIN VDE 0170/0171 - Electrical apparatus for potentially explosive atmospheres
DIN VDE 0185 - Lightning protection system, protection of structures against lightning
DIN VDE 0170/0171 - Electrical apparatus for potentially explosive atmospheres

Energy Conductors
DIN VDE 0207 - Part 1 to Part 24Insulating and sheathing components for cables and flexible cords
DIN VDE 0245 - Part 1Cables and cords for electrical and electronic equipment in power installations
DIN VDE 0245 - Part 101 to Part 202Flexible PVC insulated control cable
DIN VDE 0250 - Part 1 to Part 819Cables, wires and flexible cords for power installations
DIN VDE 0253 - Heating cables
DIN VDE 0262 - XLPE (cross-linked polyethylene) insulated and PVC sheathed installation cable up to 0.6/1kV
DIN VDE 0265 - Cables with plastic-insulated lead-sheath for power installations
DIN VDE 0266 - Part 3 to Part 4 Halogen-free cables with improved characteristics in case of fire, with reduced fire propagation and continuance of isolation for use in the containment of nuclear power plants
DIN VDE 0267 - Halogen-free cables with improved characteristics in case of fire, nominal voltages from 6kV up to 30kV
DIN VDE 0271 - PVC insulated cables and sheathed power cables for rated voltages up to and including 3.6/6 (7.2)kV
DIN VDE 0276 Part 603 - Distribution cables of nominal voltages 0.6/1kV
DIN VDE 0276 Part 604 - Power cables of nominal voltages 0.6/1kV with special fire performance for use in power stations
DIN VDE 0276 Part 605 - Additional test methods
DIN VDE 0276 Part 620 - Distribution cables of nominal voltages 3.6 to 20.8/36kV
DIN VDE 0276 Part 1000 - Current carrying capacity, general, conversion factors
DIN VDE 0276 Part 1001 - Tests on cables laid with nominal voltages 6/10kV, 12/20kV and 18/30kV with PVC insulation, VPE insulation or paper insulation
DIN VDE 0277 - Primary cables for airport lighting
DIN VDE 0281 Part 1 to Part 404 - PVC cables, wires and flexible cords for power installation
DIN VDE 0282 Part 1 to Part 808 - Rubber cables and flexible cords for power installation, heat-resistant silicone rubber insulated cable, halogen-free insulated cable, arc welding cable, rubber insulated lift cable, rubber sheathed flexible cable
DIN VDE 0284 - Mineral insulated cables with a rated voltage not exceeding 750V
DIN VDE 0289 Part 1 to Part 101- Definitions for cables, wires and flexible cords for power installation
DIN VDE 0292 - Code designation for harmonised cables and flexible cords for power installations
DIN VDE 0293 - Core identification for cables and flexible cords used in power installations
DIN VDE 0295 - Conductors of cables, wires and flexible cords for power installations
DIN VDE 0298 Part 1 to Part 300 - Application of cables and flexible cords in power installations

Measuring, Control, Testing
DIN VDE 0472 Part 1 to Part 818 - Testing of cables, wires and flexible cords
DIN VDE 0473 Part 1 to Part 811 - Insulating and sheathing materials of electric cables, common test methods
DIN VDE 0482 Part 1 to Part 268 - Measurement of smoke density

Information Technology
DIN VDE 0800 Part 1 to Part 10 - Telecommunications
DIN VDE 0811 - Ribbon cables with round conductors, with a pitch of 1.27mm
DIN VDE 0812 - Equipment wires and stranded equipment wires of telecommunications systems
DIN VDE 0813 - Switchboard cables for telecommunications systems
DIN VDE 0814 - Cords for telecommunications systems
DIN VDE 0815 - Indoor wiring cables for telecommunications systems
DIN VDE 0816 Part 1 to Part 3 - Outdoor cables for telecommunications systems
DIN VDE 0817 - Cables with stranded conductors for increased mechanical stress for telecommunications systems
DIN VDE 0818 - Self-supporting telecommunication aerial cables on overhead power lines above 1kV
DIN VDE 0839 - Electromagnetic compatibility
DIN VDE 0881 - Equipment wires and flexible equipment wires with extended temperatures
DIN VDE 0891 Part 1 to Part 10 - Special directions and guiding principles of cables and insulated wires
DIN VDE 0899 Part 1 to Part 5 - Special specification for optical fibre, single core, indoor and outdoor cables
